Prosense DP4 is an innovative gas control panel that meets tough industrial requirements. It allows monitoring explosive (LEL), toxic(ppm, VOL) gas contents in environment. The DP4 panel can manage up to 4xAnalog 4-20 mA signal gas detectors.
Ask the Expert
• Input: 4 x 4-20mA analog and 1 digital(24VDC) input allows to the user managing detectors with integrating other equipment to the systems like emergency button.
• Display: Bright and clear LCD display
• Integrity: Easy integration to SCADA systems via Modbus RS485 output
• Relays: 2 Alarm, 1 Fault and AUX adjustable relay contacts. Up to 12 extra relay outputs for specific applications
• Logging: Stores all alarm, fault and maintenance events up 24logs to provide a history of detectors connected
• Monitoring: Continuously monitoring of 4 detector gas concentrations
• Remote Control: Up to 16 S-DP4 control panel can be monitored in one center via Prosense Gas Monitoring software.
• Diversification: Different gases in different measuring ranges(ppm,LEL,VOL) can be connected
• Body: PC(Polycarbonate) superb performance under harsh environmental conditions with IP66 protection class.
• Visual/Audial: Independent Alarm and Fault LED indicators for each detector and buzzer
• Modular: Modular structure allows the user specific installation and provide efficiency during the maintenance.
| Dimensions/Weight | 366x276x186mm / 4.25 KG |
| Mounting | Modular Structure |
| Operating Temperature | -20 |
| Humidity | 10?95%RH Non-Condensing |
| Display | Graphic LCD 128x64 |
| Input | 4 x Analogue 4-20mA 1 Digital Input |
| Event Logging | Storages Alarm, Fault and maintenance logs up to 24 event |
| Relay Outputs | Programmable Fault, Alarm1, Alarm2, AUX contacts Adjustable NO/NC contacts Optional Alarm1, Alarm2 and fault relays for each detector |
| Power Consumption | 27VDC/250mA?4,5W max. without connected detectors |
| IP Rating | IP66 |
| Backup Battery Fuse | 2A |
| Monitoring | Simultaneously monitoring measurements, alarm and fault status |
| LED Indicators | 6 LED indicators for Alarm1, Alarm2, Fault, AUX, Battery and Power LED indicators |
| Software Monitoring | Up to 16 panels can be monitored via Prosense Gas Monitoring software remotely |
| Main Power Fuse | 2A |
| Power Supply | 220 VAC +/?10% - 110VAC +/-10% |
| Backup Battery | 2x12V 7A/h (Optional) |
| Programming | User friendly software enables easy programming with 4 buttons on panel door |
| Buzzer | YES |
| S-RS | RS485 Modbus RTU Interface Module |  |
| S-4RA1 | 4 Integrated Relay Modules for Alarm 1 |  |
| S-4RA2 | 4 Integrated Relay Modules for Alarm 2 |  |
| S-4RH | 4 Integrated Relay Modules for Fault |  |
| P-UZY | Prosense Monitoring Software up to 16 S-DP4 Panels |  |
| S-KEY | Panel Lock to prevent unauthorized access |  |
| SP-DP4-GBK | S-DP4/DPX004, PPS Manager Panel Transparent Lid |  |
| SP-DP4-GB | S-DP4/DPX004, PPS Manager Panel Enclosure, Without Lid |  |
| SP-DP4-TBK | DP4 Panel Board, Including Lid |  |
| SP-DP4-PS | S-DP4/DPX004/PPS için 4.4A SMPS |  |
| SP-DP8-TBK | S-DP8 Panel Board, Including Lid |  |
