    PC3 Series


    PC3 Series gas detectors can reliably detect flammable, toxic, and oxygen compounds in light industrial environments. PC3 detectors are classified as Zone 2 Category 3 devices.

    Ask the Expert

    • Sensor: Uses high quality catalytic, electrochemical sensor specially designed to detect combustible, toxic and oxygen gases.
    • Connection: Provides universal 4-20mA and Modbus RS485 outputs
    • Entry: 1 x 1/2″ NPT cable entries
    • Body: Aluminium die-cast body and sensor head superb performance under harsh environmental conditions with IP65 protection class.
    • Remote Control: Detector status can be monitored Prosense Gas Monitoring software remotely.
    • Modbus: It allows to be integrated to SCADA systems easily via open source Modbus RS485(RTU) codes
    • Relay Contacts: 2 Alarm, 1 Fault relays can be set predefined levels and can managed the other devices in case of any event.

    Sensor Technology Catalytic, Electrochemical
    Output Signal 4-20mA and Modbus RS485
    Sensor Warm-Up 60sec
    Response Time(T90) Sensor Dependent
    Accuracy %1
    Operating Temperature ‐20°C ~ +50°C
    Humidity 5 ~ 95%RH Non-Condensing
    Input Min 10VDC - Max 32VDC - Nominal 24VDC
    Power Consumption Max.2W
    Relay Outputs 2 Alarms (Selectable), and 1 Fault
    Cable Entry 1x 1/2"NPT
    IP Rating IP65
    Junction Box Epoxy Painted Die‐cast Aluminium
    Sensor Head Nickel-plated Brass
    Dimensions/Weight 230x120x100mm, 1 KG
    Hazardous Class Zone 2 ‐ Category 3
    Standards EN 60079-0
    EN 60079-1
    EN 60079-18
    1. PC3 Series Datasheet

      PC3 Series Datasheet

    2. PC3 Series User Manual

      PC3 Series User Manual

    3. CE Conformity

      CE Conformity

    4. UKCA Conformity

      UKCA Conformity

    PC3-3R+ Provides 2xAlarms, 1xFault Relay Contacts PC3-3R+
    PK-KEP Calibration Cap PK-KEP
    SP-PC3-SB04 Electrochemical Sensor Board SP-PC3-SB04
    SP-PC3-SM04-36 36 Electrochemical Sensor Module SP-PC3-SM04-36
    SP-PC3-SM04-36B 36B Electrochemical Sensor Module SP-PC3-SM04-36B
    SP-PC3-SM04-36C 36C Electrochemical Sensor Module SP-PC3-SM04-36C
    SP-PC3-SM04-44 44 Electrochemical Sensor Module SP-PC3-SM04-44
    SP-PC3-SM04-44B 44B Electrochemical Sensor Module SP-PC3-SM04-44B
    SP-PC3-SM04-44C 44C Electrochemical Sensor Module SP-PC3-SM04-44C
    SP-PC3-SM04-44D SP-PC3-SM04-44D 44D Electrochemical Sensor Module SP-PC3-SM04-44D
    SP-PC3-SM04-44E 44E Electrochemical Sensor Module SP-PC3-SM04-44E
    SP-PC3-SM04-48 48 Electrochemical Sensor Module SP-PC3-SM04-48
    SP-PC3-SM04-48B 48B Electrochemical Sensor Module SP-PC3-SM04-48B
    SP-PC3-SM04-48C 48C Electrochemical Sensor Module SP-PC3-SM04-48C
    SP-PC3-SM04-48D 48D Electrochemical Sensor Module SP-PC3-SM04-48D
    SP-PC3-SM04-48E 48E Electrochemical Sensor Module SP-PC3-SM04-48E
    SP-PC3-SM04-48F 48F Electrochemical Sensor Module SP-PC3-SM04-48F
    SP-PC3-SM04-62 62 Electrochemical Sensor Module SP-PC3-SM04-62
    SP-PC3-SM04-62B 62B Electrochemical Sensor Module SP-PC3-SM04-62B
    SP-PC3-SM04-64 64 Electrochemical Sensor Module SP-PC3-SM04-64
    SP-PC3-SM04-64B 64B Electrochemical Sensor Module SP-PC3-SM04-64B
    SP-PC3-SM04-64C 64C Electrochemical Sensor Module SP-PC3-SM04-64C
    SP-PC3-SM04-64D 64D Electrochemical Sensor Module SP-PC3-SM04-64D
    SP-PC3-SM04-64E 64E Electrochemical Sensor Module SP-PC3-SM04-64E
    SP-PC3-SM04-64F 64F Electrochemical Sensor Module SP-PC3-SM04-64F
    SP-PC3-SM04-64G 64G Electrochemical Sensor Module SP-PC3-SM04-64G
    SP-PC3-SM04-64H 64H Electrochemical Sensor Module SP-PC3-SM04-64H
    SP-PC3-SM04-64I 64I Electrochemical Sensor Module SP-PC3-SM04-64I
    SP-PC3-SM04-65 65 Electrochemical Sensor Module SP-PC3-SM04-65
    SP-PC3-SM04-66 66 Electrochemical Sensor Module SP-PC3-SM04-66
    SP-PC3-SM04-66B 66B Electrochemical Sensor Module SP-PC3-SM04-66B
    SP-PC3-SM04-66C 66C Electrochemical Sensor Module SP-PC3-SM04-66C
    SP-PC3-SM04-66D 66D Electrochemical Sensor Module SP-PC3-SM04-66D
    SP-PC3-SM04-67 67 Electrochemical Sensor Module SP-PC3-SM04-67
    SP-PC3-SM04-67B 67B Electrochemical Sensor Module SP-PC3-SM04-67B
    SP-PC3-SM04-68 68 Electrochemical Sensor Module SP-PC3-SM04-68
    SP-PC3-SM04-69 69 Electrochemical Sensor Module SP-PC3-SM04-69
    SP-PC3-SM04-69B 69B Electrochemical Sensor Module SP-PC3-SM04-69B
    SP-PC3-SM04-74 74 Electrochemical Sensor Module SP-PC3-SM04-74
    SP-PC3-SM04-75 75 Electrochemical Sensor Module SP-PC3-SM04-75
    SP-PC3-SM04-76 76 Electrochemical Sensor Module SP-PC3-SM04-76
    SP-PC3-SM04-79 79 Electrochemical Sensor Module SP-PC3-SM04-79
    SP-PC3-SM04-79B 79B Electrochemical Sensor Module SP-PC3-SM04-79B
    SP-PC3-SM04-82 82 Electrochemical Sensor Module SP-PC3-SM04-82
    SP-PC3-SM04-82B 81B Electrochemical Sensor Module SP-PC3-SM04-82B
    SP-PC3-SM04-83 83 Electrochemical Sensor Module SP-PC3-SM04-83
    SP-PC3-SM04-84 84 Electrochemical Sensor Module SP-PC3-SM04-84
    SP-PC3-SM04-86 86 Electrochemical Sensor Module SP-PC3-SM04-86
    SP-PC3-SM04-87 87 Electrochemical Sensor Module SP-PC3-SM04-87
    SP-PC3-SM04-88 88 Electrochemical Sensor Module SP-PC3-SM04-88
    SP-PC3-SM04-89 89 Electrochemical Sensor Module SP-PC3-SM04-89
    SP-PC3-SM04-95 95 Electrochemical Sensor Module SP-PC3-SM04-95
    SP-PC3-SM04-96 96 Electrochemical Sensor Module SP-PC3-SM04-96
    SP-PC3-ST01-72 72 Semiconductor Sensor Head SP-PC3-ST01-72
    SP-PC3-ST01-90 90 Semiconductor Sensor Head SP-PC3-ST01-90
    SP-PC3-ST01-91 91 Semiconductor Sensor Head SP-PC3-ST01-91
    SP-PC3-ST02-HC HC LEL Catalytic Sensor Head SP-PC3-ST02-HC
    SP-PC3-ST04-36 36 Electrochemical Sensor Head SP-PC3-ST04-36
    SP-PC3-ST04-36B 36B Electrochemical Sensor Head SP-PC3-ST04-36B
    SP-PC3-ST04-36C 36C Electrochemical Sensor Head SP-PC3-ST04-36C
    SP-PC3-ST04-44 44 Electrochemical Sensor Head SP-PC3-ST04-44
    SP-PC3-ST04-44B 44B Electrochemical Sensor Head SP-PC3-ST04-44B
    SP-PC3-ST04-44C 44C Electrochemical Sensor Head SP-PC3-ST04-44C
    SP-PC3-ST04-44D 44D Electrochemical Sensor Head SP-PC3-ST04-44D
    SP-PC3-ST04-44E 44E Electrochemical Sensor Head SP-PC3-ST04-44E
    SP-PC3-ST04-48 48 Electrochemical Sensor Head SP-PC3-ST04-48
    SP-PC3-ST04-48B 48B Electrochemical Sensor Head SP-PC3-ST04-48B
    SP-PC3-ST04-48C 48C Electrochemical Sensor Head SP-PC3-ST04-48C
    SP-PC3-ST04-48D 48D Electrochemical Sensor Head SP-PC3-ST04-48D
    SP-PC3-ST04-48E 48E Electrochemical Sensor Head SP-PC3-ST04-48E
    SP-PC3-ST04-48F 48F Electrochemical Sensor Head SP-PC3-ST04-48F
    SP-PC3-ST04-62 62 Electrochemical Sensor Head SP-PC3-ST04-62
    SP-PC3-ST04-62B 62B Electrochemical Sensor Head SP-PC3-ST04-62B
    SP-PC3-ST04-64 64 Electrochemical Sensor Head SP-PC3-ST04-64
    SP-PC3-ST04-64B 64B Electrochemical Sensor Head SP-PC3-ST04-64B
    SP-PC3-ST04-64C 64C Electrochemical Sensor Head SP-PC3-ST04-64C
    SP-PC3-ST04-64D 64D Electrochemical Sensor Head SP-PC3-ST04-64D
    SP-PC3-ST04-64E 64E Electrochemical Sensor Head SP-PC3-ST04-64E
    SP-PC3-ST04-64F 64F Electrochemical Sensor Head SP-PC3-ST04-64F
    SP-PC3-ST04-64G 64G Electrochemical Sensor Head SP-PC3-ST04-64G
    SP-PC3-ST04-64H 64H Electrochemical Sensor Head SP-PC3-ST04-64H
    SP-PC3-ST04-64I 64I Electrochemical Sensor Head SP-PC3-ST04-64I
    SP-PC3-ST04-65 65 Electrochemical Sensor Head SP-PC3-ST04-65
    SP-PC3-ST04-66 66 Electrochemical Sensor Head SP-PC3-ST04-66
    SP-PC3-ST04-66B 66B Electrochemical Sensor Head SP-PC3-ST04-66B
    SP-PC3-ST04-66C 66C Electrochemical Sensor Head SP-PC3-ST04-66C
    SP-PC3-ST04-66D 66C Electrochemical Sensor Head SP-PC3-ST04-66D
    SP-PC3-ST04-67 67 Electrochemical Sensor Head SP-PC3-ST04-67
    SP-PC3-ST04-67B 67B Electrochemical Sensor Head SP-PC3-ST04-67B
    SP-PC3-ST04-68 68 Electrochemical Sensor Head SP-PC3-ST04-68
    SP-PC3-ST04-69 69 Electrochemical Sensor Head SP-PC3-ST04-69
    SP-PC3-ST04-69B 69B Electrochemical Sensor Head SP-PC3-ST04-69B
    SP-PC3-ST04-74 74 Electrochemical Sensor Head SP-PC3-ST04-74
    SP-PC3-ST04-75 75 Electrochemical Sensor Head SP-PC3-ST04-75
    SP-PC3-ST04-76 76 Electrochemical Sensor Head SP-PC3-ST04-76
    SP-PC3-ST04-79 79 Electrochemical Sensor Head SP-PC3-ST04-79
    SP-PC3-ST04-79B 79B Electrochemical Sensor Head SP-PC3-ST04-79B
    SP-PC3-ST04-82 82 Electrochemical Sensor Head SP-PC3-ST04-82
    SP-PC3-ST04-82B 81B Electrochemical Sensor Head SP-PC3-ST04-82B
    SP-PC3-ST04-83 83 Electrochemical Sensor Head SP-PC3-ST04-83
    SP-PC3-ST04-84 84 Electrochemical Sensor Head SP-PC3-ST04-84
    SP-PC3-ST04-86 86 Electrochemical Sensor Head SP-PC3-ST04-86
    SP-PC3-ST04-87 87 Electrochemical Sensor Head SP-PC3-ST04-87
    SP-PC3-ST04-88 88 Electrochemical Sensor Head SP-PC3-ST04-88
    SP-PC3-ST04-89 89 Electrochemical Sensor Head SP-PC3-ST04-89
    SP-PC3-ST04-95 95 Electrochemical Sensor Head SP-PC3-ST04-95
    SP-PC3-ST04-96 96 Electrochemical Sensor Head SP-PC3-ST04-96
    SP-SH10-SIN SH10/20 Sensör Başlıkları İçin Sinter (10'lu Paket) SP-SH10-SIN
    SP-PC3-GB PC3 Series Enclosure (Excluding Lid) SP-PC3-GB
    SP-PC3-GB-N PC3 Series PC3 Lid SP-PC3-GB-N
    SP-PC3-TB01 01 PC3 Series Transmitter SP-PC3-TB01
    SP-PC3-TB04 04 PC3 Series Transmitter SP-PC3-TB04
    SP-PC3-TB02 02 PC3 Series Transmitter SP-PC3-TB02
